1/8" Tube X 1/8" MNPT Stopcock

This 1/4" MNPT X 1/4" MNPT Stopcock is designed for controlling fluid streams between tubing connections. Made from PFA and PTFE, it offers a service temperature range from ‑328°F to 500°F (‑200°C to 260°C). It can be added to the side or bottom of vessels for use as a drain, with a pressure rating of 50 PSI up to 150°F (66°C). For every 2°F rise above 150°F, subtract 1 PSI from the 50 PSI rating.

Features:

• Service temperature range of PFA: ‑328°F to 500°F (‑200°C to 260°C)
• All parts in contact with fluid stream are PFA and PTFE
• Can be added to the side or bottom of vessels for use as a drain
• Can be used to control fluid stream between tubing connections
• Pressure rating: 50 PSI up to 150°F (66°C)
• Subtract 1 PSI from 50 PSI for every 2°F/‑17°C rise above 150°F/66°C

Specifications:

• Connection Type: 1/4" MNPT X 1/4" MNPT
